PVC Pipe Haul Off unit

PVC Pipe Haul Off unit Specification

Features
Precise pulling force, Adjustable speed control, Durable construction

Capacity
Up to 250 kg/hr

Motor Power
2.2 kW AC Motor

Drive Type
Belt Drive

Surface Finish
Powder Coated

Diameter
Suitable for pipe diameter ranging from 20 mm to 250 mm

Noise Level
Low Noise, Less than 75 dB

Size
Standard (Customizable depending on pipe diameter)

Shape
Rectangular Base, Belted Pulley Mechanism

Lubricating System
Centralized Lubrication

Usage & Applications
PVC Pipe Extrusion Line - Suitable for pulling PVC pipes during manufacturing process

Product Type
Haul Off Machine

Material
Steel

Technology
Mechanical Pulling Mechanism

Power Source
Electric

Power
2.2 kW (Standard)

Voltage
220-240 Volt (v)

Pressure
Ambient (Atmospheric Pressure)

Surface Treatment
Coated

Dimension (L*W*H)
1800 mm x 900 mm x 1350 mm

Weight
Approx. 750 kg

Color
Blue

Maximum Pulling Force
Up to 2000 N

Serviceability
Easy maintenance access panels

Ambient Working Temperature
0°C to 50°C

Traction Speed
Adjustable up to 20 m/min

Belt Material
Abrasion Resistant Rubber

Type of Adjustment
Automatic and Manual Adjustment available

Installation
Floor Mounted

Number of Tracks
2 or 4 Tracks (Depending on model)

Compatibility
Compatible with PVC, UPVC, CPVC pipe lines

Safety Features
Emergency Stop, Overload Protection

Protective Cover
Transparent safety cover over tracks

Pipe Handling Capacity
Multiple pipe sizes at once (customization possible)

Control Panel Type
Digital/PLC Based Control Panel

PVC Pipe Haul Off unit Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
10 Days

About PVC Pipe Haul Off unit

Get the acclaimed, hot-selling PVC Pipe Haul Off unitperfect for boosting extrusion line efficiency. Triumphant in quality, this best-in-class machine is available in 2 or 4 track models, with traction speeds adjustable up to 20 m/min. Its digital/PLC-based control panel ensures optimum precision, managing multiple pipe sizes simultaneously. With emergency stop and overload protection, maintenance is hassle-free via accessible panels. Compatible with PVC, UPVC, and CPVC, this floor-mounted unit features abrasion-resistant belts and powder-coated steel for ultimate durability. Suitable for pipes 20250 mm, it delivers up to 2000 N pulling force with low noise.

Versatile Application & Easy Operation

Optimized for broad application media, the PVC Pipe Haul Off unit is suitable for manufacturing and pulling PVC, UPVC, and CPVC pipes of various diameters. Its designed for seamless operation in extrusion linesjust align the pipe, adjust the traction speed, and set the direction through the intuitive digital control panel. Ideal for use in industrial pipe production, the unit handles multiple pipe sizes with automated or manual adjustments for unmatched flexibility and accuracy in production.

Premium Packaging, Swift Supply & Payment Flexibility

Our PVC Pipe Haul Off units are shipped in robust, premium-quality packaging to ensure safe delivery. Benefit from quick dispatch and reliable shipping across India, with supply ability tailored to large or customized orders. Payment terms are flexibly designed to accommodate distributor, exporter, importer, supplier, and manufacturer requirements, reinforcing a smooth transaction experience from order placement to installation. Customer satisfaction and timely supply are always a priority.

FAQs of PVC Pipe Haul Off unit:

Q: How does the PVC Pipe Haul Off unit adjust to different pipe sizes?

A: The unit can process multiple pipe sizes simultaneously, thanks to its customizable design and automated/manual adjustment options that adapt tracks and belt positions to suit various diameters from 20 mm to 250 mm.

Q: What safety features are included in this haul off unit?

A: It comes with robust safety features such as an emergency stop button, overload protection, and a transparent safety cover over the tracks, ensuring secure operation during the manufacturing process.

Q: Where can this PVC Pipe Haul Off unit be installed?

A: The unit is designed for floor-mount installation, making it ideal for factory environments, pipe manufacturing plants, and PVC extrusion lines.

Q: What is the process for maintaining the Haul Off unit?

A: Maintenance is straightforward with easy-access panels and a centralized lubricating system, allowing routine service and quick inspection to maximize uptime without lengthy downtime.

Q: What are the major benefits of using this hot-selling haul off unit?

A: Users benefit from precise pulling force, adjustable speed control, durable construction, low noise operation, and broad compatibility with PVC, UPVC, and CPVC pipe lines, making it a perfect choice for modern pipe production.
